Vision & Mission
We are committed to serve the interests of all our customers by being reliable, efficient and exceed our customers expectations in quality, delivery and cost through continuous improvement and customer interaction.
To provide first-class quality and innovative machine tools and service in response to our customer's needs. As well as continuously improve in order to meet the ever changing needs of our customers by introducing new efficient technology and machinery's.
List of Machinery
AMS 400
Specifications:
| X axis |
600 mm |
| Y axis |
500 mm |
| Z axis |
500 mm |
| Table size |
450 x 900 mm |
| Spindle shank |
BT 40 |
| No of tools |
20 |
BFW BMV 50
Specifications:
| X axis |
800 mm |
| Y axis |
510 mm |
| Z axis |
510 mm |
| Table size |
1000 x 510 mm |
| Pallet Bed |
480 x 900 mm |
| No. of Pallet |
2 |
| Max load on table |
400 kg |
| No. of tools |
20 |
| Spindle shank |
BT50 |
BFW Xtron 955 VMC
Specifications:
| X-Axis | 900 mm |
| Y-Axis | 500 mm |
| Z Axis |
500 mm |
| Table dimension |
1100 x 510 mm |
| Max load on Table |
900 Kg |
| Spindle Motor |
5.5 kw / 7.5 kw |
| No of tools |
24 nos |
| Power capacity |
22 KVA |
Feeler 850A VMC
Specifications:
| X-Axis | 850 mm |
| Y-Axis | 500 mm |
| Z-Axis | 500 mm |
| Table dimension |
425 x 950 mm |
| Max load on Table |
500 Kg |
| Spindle Motor |
7.5 kw/9 kw |
| No of tools |
24 nos |
| Power capacity |
15 KVA |
Horizontal Milling FN3H
Specifications:
|
Overall dimension (LxW) |
2050 x 355 mm |
|
Clamping Area (LxW) |
1600 x 355 mm |
|
Transverse Axis |
1200 mm |
|
Longitudinal Axis |
320 mm |
| Cross Vertical Axis |
425 mm |
| Max weight on bed |
600 Kg |
|
Number of speeds |
18 |
|
Speed range |
25.5-1800 Rpm |
|
Main motor |
7.5 kw /1500 Rpm |
|
Feed motor |
3.7 kw / 3000 Rpm |
Vertical Milling FN3V
Specifications:
| Overall dimension (LxW) |
2050 x 355 mm |
| Clamping Area (LxW) |
1600 x 355 mm |
| Transverse Axis |
1200 mm |
| Longitudinal Axis |
320 mm |
| Cross Vertical Axis |
425 mm |
| Max weight on bed |
600 Kg |
| Number of speeds |
18 |
| Speed range |
25.5-1800 Rpm |
| Main motor |
7.5 kw /1500 Rpm |
| Feed motor |
3.7 kw / 3000 Rpm |
Radial Drilling RM51
Specifications:
| Drilling Capacity |
50 mm |
| Drilling Depth |
325 mm |
| Spindle Speed |
12:40-1800 Rpm |
| Spindle feed (no:mm/rev) |
6:0.125-1.25 |
| Main motor |
3.8 kw |
| Elevation motor |
1.5 kw |
| Spindle Bore size |
MT2 |
| Working table size (LxW) |
740 x 580 mm |
Shimoga Lathe
Specifications:
| Centre Height |
300 mm |
| Working Length |
850 mm |
Anil Lathe
Specifications:
| Centre Height |
170 mm |
| Working length |
550 mm |
FN2U MILLING MACHINE
Specifications:
| Capacity |
1520 x 310 mm |
| Clamping area(LxW) |
1350x310 mm |
| Longitudinal |
265mm |
| Cross vertical |
400 mm |
| Speed range |
35.5-1800 RPM |
HMT LB-17 LATHE
Specifications:
| Make | HMT |
| Model | LB-17 |
| Length | 6 Feet |
| Center Height | 170 mm |
| Swing over the Bed | 340 mm |
Inspection Facilities
Accurate Spectra CMM 685
Specifications:
X Axis |
600 mm |
Y Axis |
800 mm |
Z Axis |
500 mm |
Luthra Make Granite Surface Plate
Specifications:
SIZE |
1600 X 1000 X 150 MM |
GRADE |
'O' |
Measuring Instruments
PARTICULARS |
RANGE |
RESOLUTION |
DIGIMATIC HEIGHT GAGE SINGLE COLUMN |
0-600 mm |
0.01 mm |
OUTSIDE MICROMETER |
0-25 mm |
0.01 mm |
OUTSIDE MICROMETER
|
25-50 mm |
0.01 mm |
OUTSIDE MICROMETER
|
50-75 mm |
0.01 mm |
OUTSIDE MICROMETER
|
75-100 mm |
0.01 mm |
BORE GAGE WITHOUT DIAL |
18-35 mm |
|
BORE GAGE WITHOUT DIAL
|
35-60 mm |
|
DIAL INDICATOR |
1 mm |
0.001 mm |
DIAL TEST INDICATOR(Horizontal Type) |
0.8 mm |
0.01 mm |
MAGNETIC 'V' BLOCK (Set) |
100 X 95 X 70 mm |
|
